Assessment of Bacterial Leaf Blight Incidence and Severity in Rice Growing Areas of Pakistan

Pakistan is an agricultural country, blessed with favorable temperature and climate for the production of rice. It is imperative to mention that rice being the 3rd most important crop of Pakistan, it is covering over 10% of total land area for cultivation and contributes about 17% in the production of cereal grains of the country (Ali et al., 2009; Hussain et al., 2008).

By increase in international travel and trade, there is a threat of introduction of many pathogenic species and pest in the agricultural sector (Graham et al., 2004). A considerable amount of rice crop is lost every year due to the infestation of diseases caused by numerous bacteria, viruses and fungi. Leaf blast, bacterial leaf blight (BLB) and sheath blight are categorized as the three most damaging diseases of cultivated rice. Among these three, most serious and devastating disease of the rice crop in Asian continent is BLB which is caused by the pathogen, Xanthomonas oryzae pv. oryzae (Xoo) (Yang, 2010; Arshad et al., 2017). The disease is very much common in Asia, Australia, Latin America and United States. However, it was reported first time in Kyushu, Japan during 1884-85 (Yamanuki et al., 1962).

Bacterial leaf blight early symptoms appear on the leaf blades at tillering stage, starting from lower plant parts and then reaching to above ones. (Goto, 1992; Cha, 1982). In case of severe attack, the disease is clearly visible in vulnerable genotypes receiving nitrogen fertilizer higher dosage. The entire leaf blade area turns pale yellow (Mizukami and Wakimoto, 1969). In most damaging case, yellow to white stripes are seen just inside the margins of the leaf blades, turning yellow and at the end result in mortality of leaf tissues (Ou, 1985).

During 1985 the yield losses by BLB were reported between 25-35% in Japan (Ou, 1985). Similarly, high yield losses (24-50%) were reported in Philippines (Exconde, 1973) and India 12-32% (ShahJahan, 1992). In Pakistan, it is expanding its area year after year. Almost all famous varieties of Pakistan’s Basmati rice are susceptible to this disease. BLB cause yield losses due to decrease in photosynthetic activities of plant. Losses may range from 30-50% to 100% in case bacterial infection occurs at tillering stage of crop (Khan et al., 2012).

It has been observed that high speed winds along with rain favor the BLB spread. Sometimes, other mechanical means spread the disease to change it into an epidemic. (Muko et al., 1957; Srivastava, 1972). Some of the scientists reported that genotype of the variety plays important role in susceptibility (Singh et al., 1977) while, others stated that field management (Ou, 1985) also contribute in the disease development. Therefore, disease estimation at right time and management strategies implemented accordingly let the crop yield to improve within stipulated time.

In Pakistan, BLB disease was first reported in 1977 at Kala Shah Kaku, Rice Research Institute (Mew and Majid, 1977). It was also reported in the paddy rice cultivars, Palmaan, IRRI 6, and Basmati 198 (Ahmad and Majid, 1980). BLB incidence is increasing in Pakistan especially in Kallar belt known for producing high quality Basmati rice with special aroma (Khan et al., 2000). In addition, BLB is increasing in many farmer fields of KP, Punjab and Sindh, 21-26%, 16-22% and 11-16%, respectively (Akhtar and Sarwar, 1986). Therefore, present study was planned to check the current status of BLB in major rice growing areas of Pakistan. The data generated by the study is helpful for researchers to assess disease scenario under climate change scenario.

Major rice growing areas of Punjab, KP and Sindh provinces were surveyed during the year 2019-20. In Punjab province; Sargodha, Hafizabad, Sheikhupura, Sialkot, Narowal, Gujranwala, Wazirabad, Zafarwal and Gujrat districts were surveyed. In KP, Mansehra, Swat and Lower Dir districts were surveyed for the presence and severity of BLB. Shikarpur, Sukkur, Jacobabad, Nawab shah, Tando Muhammad Khan, Badin, Sajawal and Thatta of Sindh province were recorded for BLB incidence and severity.

During the field surveys, positive sampling was done and rice leaves naturally infected with BLB were collected at pre-panicle stage, with appearance of yellow to white water-soaked stripes lesions at the margins of infected leaves (Figure 1D and E). Leaves were sliced into 0.5–1 cm length from an area where the lesion is still advancing.

Data on disease prevalence, incidence and severity was recorded using following formulas:

Prevalence (%): Prevalence is on the basis of presence or absence of BLB in the field.

Incidence (%): Number of diseased plants/Total plants observed x 100

Severity (%): Severity was recorded by taking the percentage of leaf area infected by BLB using following scale (IRRI, 1996).

Infected parts of BLB leaves were disinfected in 70% ethanol for 1 minute. The leaf tissues were rinsed thrice with double distilled water and cut in to small pieces with sterilized scissor and dipped in double distilled water in micro centrifuge tube for 1 hour for bacteria to be oozed out (Figure 2A and B). Bacterial suspension in water was streaked on Wakimoto’s media and kept in incubator for 5-7 days at 28-30°C (Figure 2C). Lemon yellow colored single colonies with shiny circular surface were picked and purified on fresh Wakimoto’s media plates (Figure 4A). For long-term storage, the purified cultures were preserved at-20 °C and -80°C in 1:1 of 50% glycerol and Nutrient broth.

Multiplex colony PCR (Vera-Cruz et al., 2017) was done, using primers, Xo3756 (331bp), Xoo80 (162bp) and Xoc3866 (691bp); for identification of Xanthomonas oryzae, Xanthomonas oryzae pv. oryzae and Xanthomonas oryzae pv. oryzicola respectively (Figure 3C).

The pathogenicity of Xoo isolates were confirmed under field conditions, using leaf clip method (Kauffman et al., 1973). Forty-five days old seedlings of susceptible rice cultivar (Super Basmati) were used for inoculation. The leaves were clip-inoculated at 1-2cm from tip with sterile scissors that had been dipped in the bacterial suspension containing 108 CFU/ml (Figure 4A).

The lesion length was measured after 14 days of inoculation as follows: 0-5cm=R, 6-10cm=MR, 11-15cm= MS, above 15cm= S (IRRI, 1996).

BLB was prevalent in all the surveyed provinces of Pakistan (Figure 1A, B and C). In Punjab, high disease prevalence was observed in Gujranwala (55%), Hafizabad (36%), Sialkot (29%) and Narowal (27%). No disease was observed in Wazirabad, Zafar Wal and Gujrat. The disease incidence in Gujranwala, Sialkot and Narowal was 35%, 21% and 50%, respectively and severity ranges from 0-9, 0-7 and 0-7, respectively. In KP 3 rice growing areas were surveyed. The disease prevalence was high in Swat (20%) and Mansehra (12%). In Mansehra the disease incidence (37%) and severity (0-7) was high compared to Swat and lower Dir. In Sindh disease was less prevalent. Highest disease prevalence was recorded in Badin (13%) followed by 10% in Shikarpur (Table 1).

Forty-seven diseased leaf samples were collected from the entire surveyed locations and processed for isolation and further studies. Yellowish colonies of bacteria were consistently isolated and purified. (Figure 3A and B). Thirty isolates have been confirmed through PCR which yielded a band size of 162bp on gel (Figure 3C).

All positive isolates (confirmed by PCR) were inoculated on susceptible rice cultivar (Super Basmati) for confirmation of their pathogenicity. All isolates showed typical symptoms with white to yellows stripes from top to bottom of leaves with wavy margins after 21 days of inoculation (Figure 4A, B and C).

BLB of rice is known to cause severe losses when comes in epidemic form. In the current study BLB was prevalent in all the 3 surveyed provinces. In Punjab and KP the disease incidence and severity were high compared to Sindh. Similar pattern of high incidence and severity has been reported previously from Punjab (Sialkot, Narowal, Hafizabad, Gujranwala and Sheikhupura) and KP (Lower Dir, Swat and Mansehra) by different researchers. However, in Sindh generally low disease incidence and severity was reported except for Badin where incidence up to 40% have been reported (Akhtar and Sarwar, 1986; Akhtar et al., 2003; Rafi et al., 2013). The severity of the diseases varied among different rice growing zones because of the crop age. It has been found that some of the varieties show severe symptoms during vegetative stage and others show aggressiveness near maturity (Philip and Devadth, 1980). Similar results were also reported in Korea by Cha et al., 1982. who observed maximum incidence in young age plants.

Table 1: Status of bacterial leaf blight of rice in Punjab, KP and Sindh during 2019-20 season.

The diseased samples collected were processed for isolation of Xoo. In most of the previous studies from Pakistan biochemical, morphological or some other primers have been used to identify Xoo. In this study multiplex PCR recommended by IRRI, Philippines was used to identify the suspected Xoo isolates (Vera Cruz et al., 2017). A number of primers for Xoo have been reported in the literature (Niño-Liu et al., 2006; Sakthivel et al., 2001; Lang et al., 2010). Multiplex PCR was used in this study as it simultaneously detects Xoo and differentiate its close relative, Xanthomonas oryzae pv. oryzicola (Xoc). Thirty isolates were confirmed as Xoo and all isolates produced blight symptoms on rice with no significant differences in severity on rice plants.

The previous and current studies showed that BLB is consistently present in all the major rice growing districts of Punjab from last 20-25 years. This is due to the fact that mostly old basmati varieties such as super basmati and others which lack effective resistance genes against BLB are being cultivated on major area. In KP susceptible varieties Bas-385, Begumie, JP-5 and Fakhr-e-Malakand, Swat-1 and Swat-11 are still being cultivated. The infected seed of these cultivars is the reason of introduction of the pathogen directly into the rice nurseries (Akhtar and Zakria, 2003; Akhtar et al., 2003; Naqvi, 2019). In Sindh mostly imported hybrids are being cultivated which generally have better resistance against BLB and this might be the reason of low incidence. To date about 45 bacterial leaf blight resistance genes (R) have been reported (Busungu et al., 2016; Liang et al., 2017). However, pathogen is changing continuously and new races of Xoo are emerging which break down the resistance provided by R genes (Lore et al., 2011). So, it is necessary to breed and introduce varieties with effective resistance against BLB which will help in reducing the yield losses and also the inoculum pressure in the field.

BLB is highly dependent on favorable environmental conditions (high temperature and rainfall) for its establishment and also depend on mechanical means for its spread (Yang, 2010; Goto et al., 1955). Heavy rainfalls in the month of August and September have effect on the intensity of BLB in the field. The strains isolated during the reporting period will be subjected to pathotyping and identification of resistance sources. The information generated will help in understanding the race spectrum of Pakistani Xoo isolates and will also give the information that which BLB resistant genes are stable/broke down against these races.

In this manuscript Bacterial blight of rice diseases status during 2019-20 is reported and the confirmation of its pathogen i.e. Xanthomonas oryzae pv. oryzae was done on molecular basis.

Rafia Ahsan, Saif Ullah, Ijaz yaseen, Faisal Sohail Fateh and Muhammad Sufyan: Conducted the experiments.

Muhammad Fayyaz and Atif Jamal: Performed data analysis.

Shahzad Asad: Wrote manuscript.

Muhammad Zakria: Conceived the idea and wrote manuscript.

The authors have declared no conflict of interest.
